- Dynamic Box Design acc. to GMP-Guideline easy to clean and to disinfect
- Doubled Skin Cabinet with Doors and Toughed Glass
- Cabinet Fabricated in SS 304/316 Structure
- Re-Circulated Filtration System
- Electro Magnetic Interlocking System
- HEPA filter H14 filter for supply air and exhaust air
- EU-6 Grade Pre-Filter With SS 304 Flange
- Air velocity: 0.45±0.05 mps (90±20FPM) Below Six Inch of Grill
- Magnehelic Differential pressure gauge
- Centrifugal type Air blower with Speed Variable
- Measuring system for pressure differential and volume flow or air velocity (If Required)
- Pre-Installed White and UV Germicidal Light
- Feather Touch controller for Blower/Light/Pressure Display
- DOP Port/Atmospheric Nozzles
- Sound Level Minimum 65db On Scale
- Power Supply Single Phase 220V 50 Hz
Functioning
- Digital Pressure Gauge with Alarm Hour Meter
OPTIONAL FEATURES
- It is a rectangular compartment and it has two doors at its extreme.
- The doors have a glass viewing window so that the material kept for transfer can be seen.
- One door opens in the cleanroom and the other one opens in the other room.
- Both the doors are electrically interlocked type, hence it only allows one door to be opened at a time.
- It restricts the direct air flow between the cleanroom to the other room.
- It also reduces the need for opening the cleanroom door frequently for transferring the material.
- It helps in fulfilling the aim of transferring the material without compromising the level of cleanliness in the cleanroom.
- The Dynamic Pass Boxes is specially designed Pass Box, that is fitted with HEPA Filter.
- The Dynamic Box acts as a pressure chamber and it only allows clean air to enter the clear room while maintaining the cleanliness level of a cleanroom.
Dynamic Pass Box Features
- Easy to clean
- Easy to integrate
- Advanced air tightness
- Interlocking System
- Heavy duty body
- UV light
Dynamic Pass Box Applications
- Medical implant
- Medical devices
- Educational institution
- Vaccine manufacturers
- Pharmaceutical industry
- Electronic industry
- Food processing industry
- Chemical research laboratories
- Semiconductor production
